We are pleased to invite you to our Semiconductor Open House where we will showcase our latest technological trends in semiconductor manufacturing. Together with external partners we will focus on the mass production fabrication needs of emerging Photonic Integrated Circuits applications.

Attending PIC Summit Europe in Eindhoven? Continue your journey with us - just 30 minutes away from Frankfurt Airport! Network with industry leaders and experience the world’s leading ion beam solutions for your next-generation PICs. Take this chance to stay ahead of the competition and accelerate your photonics roadmap.

+




What to expect?

Experience next-level innovations and enjoy groundbreaking presentations by the semiconductor experts at Bühler Leybold Optics, showcasing the latest trends and breakthroughs with PICs as the main focus:

  • Ion beam trimming can improve wafer uniformity for higher yields and low microroughness for less stray light in the waveguides
  • Plasma-Assisted Reactive Magnetron Sputtering enables highly precise control of the optical properties during the growth of waveguide materials

We are also joined by industry leaders who will speak about the market needs as PICs take the next steps towards industrialization. Because every photon counts!

Join the official inauguration of the class 1000 Semiconductor Cleanroom, along with a guided tour through our application lab, our production facility and our “Service Solution World.

Networking and exchange on the latest technologies driving the industry.

Want to schedule a personalized meeting? Let us know what special topics you are interested in, and we will create a customized schedule for you.

Our solutions

Bühler Leybold Optics is a leading supplier for thin-film vacuum coating solutions. Our sputtering coating equipment includes the cutting-edge technologies from the precision optics market, upgraded to meet the demands of the semiconductor industry, backed by experienced engineers, to optimize performance and productivity for almost any application.​
